Prosport Coilover Kit – BMW 5 Series F10 (Saloon/Facelift)

Description

Prosport Coilover Kit – BMW 5 Series F10 (Saloon/Facelift)

Prosport Coilovers: 5 Series Saloon F10, 5 Series Facelift Saloon F10

Key Features:

Zinc-plated coilover struts for a quality finish with enhanced corrosion protection.
Blue Powder-Coat finish on the springs.
Includes front helper springs for improved main spring control
Engineered to give the best balance between firmly controlled handling and comfort.

Fits:

This Prosport Coilover Kit will fit these:

BMW 5 Series F10 Saloon models, made from 2010-2014: 520i/523i/528i/530i/535i/520d/525d/530d/535d, Not suitable for XDRIVE or vehicles with EDC, Includes Facelift (LCI) models.

BMW 5 Series F10 Facelift (LCI) Saloon models, made from 2014-2017: 520i/523i/528i/535i/518d/520d/525d/530d/535d, Not suitable for XDRIVE or vehicles with EDC, Includes Facelift (LCI) models.

Lowering Range:

Front: 35-60mm
Rear: 35-60mm

Product Specifications in Detail:

Front Shock Absorber Type: Twin-Tube with pressurised gas
Rear Shock Absorber Type: Twin-Tube with pressurised gas
Front Spring Type: Linear with helper spring
Rear Spring Type: Progressively wound
Maximum Front Axle Load: 1280kg
Maximum Rear Axle Load: 1450kg
Zinc plated front and rear Coilover units
Blue EPS Powder Coating on the springs
Alloy adjustment and lock rings on the Coilover Units
TUV Quality Certification: Yes – Find out more about TUV here: https://en.tuv.at/inspection-and-approval/

Good to Know:

These Prosport Coilovers are designed to fit on to the standard (OEM) top mounts.
No additional parts needed for installation of this Prosport Coilover Kit.
TUV Quality Certification.
1 year warranty.
We recommend having the suspension geometry checked and adjusted after fitting these Coilovers.
To ensure both optimum performance and reliability, always keep within the lowering range shown above.
Vehicles with M-Sport suspension will lower by less than the stated figures.

In the box:

Front Coilovers x2
Rear Coilovers x2
Tools for setting ride height
