ACL Thrust Washers Honda B-Series D-Series K-Series – 1T1957-STD

Description

ACL Thrust Washers Honda – 1T1957-STD

The thrust washers are a small part, but they control crankshaft end float. They take the axial load every time you press the clutch, so worn ones show up as excessive crank end play. The ACL Thrust Washers Honda set 1T1957-STD is a single ACL part number, and the same pair suits the D-series, almost all of the B-series, the later H22 and the K20 and K24 family. One pack contains the 2 half washers needed for one engine.

Why replace thrust washers on a rebuild?

Whenever the crank comes out, for a fresh set of main and rod bearings, a regrind or a forged internals build, it makes sense to fit new thrust washers at the same time. That’s especially true on a car running an uprated clutch, where the higher clamp load goes straight into the thrust faces. Check crank end float with a dial gauge once the main caps are torqued. Compare the reading against the figure for your engine.

ACL Thrust Washers Honda 1T1957-STD at a glance

Each pack of ACL Thrust Washers Honda 1T1957-STD contains the two halves shown in the photo, enough for one engine.

• ACL part number: 1T1957-STD (standard size).
• Contents: 2 thrust washer halves, enough for one engine.
• One part number covers D, B, H and K-series applications, so it’s easy to keep one on the shelf for any Honda build.

Pair with ACL Race Series bearings

Most builders order these alongside the ACL 5M1959H main bearings and the correct rod set for their engine:

• B16A / B18B rod bearings
• B18C rod bearings
• K20 / K24 rod bearings

The set listings for the K20, B18C and B16A let you choose all three bearing types on one page. Browse the full ACL Bearings range. ACL’s own Race Series catalogue lists every application.

Engines these thrust washers fit

• Honda D16A, D16B, D16W, D16Y, D16Z and D17A, D17Z
• Honda B16A, B17A1, B18A1, B18B1, B18B2
• Honda B18C1, B18C2, B18C5, B18C7
• Honda B18A, B20A (SOHC), and B20A, B21A, B21A1 (DOHC)
• Honda B20B, B20Z
• Honda H22A, H22Z (1998 on)
• Honda K20A2, K20A3, K20Z1, K20C1, K24A, K24Z1

Honda models this fits

The ACL Thrust Washers Honda 1T1957-STD set is linked to these models in our car filter:

• Honda Civic [EF/EF9] (1988-1992) – EF9 1.6i-VT / SiR (B16A)
• Honda Civic [EG/EG6] (1992-1995) – EG6 VTi (B16A2)
• Honda Civic [EK] (1996-2000) – EK4 VTi (B16A2)
• Honda CRX [ED] (1983-1993) – ED9 1.6i-VT (B16A)
• Honda Del Sol (1992-1998) – Del Sol VTi (B16A2)
• Honda Integra [DC2] (1994-2001) – Integra Type R (B18C)
• Honda Civic [EP/EP3] (2001-2005) – Civic Type R EP3 (K20A2) – not the 1.6 EP2
• Honda Integra [DC5] (2001-2006) – Integra Type R DC5 (K20A, Japanese import)
• Honda Accord [Cl7] (2004-2008) – Accord 2.4 (K24A) – not the 2.0
• Honda Civic [FK7/FK8] (2017-2021) – Civic Type R FK8 (K20C1) – not the FK7
• Honda Civic [FL5] (2023+) – Civic Type R FL5 (K20C1)
• Honda Prelude (1997-2001) – Prelude 2.2 VTi (H22A, 1998 on)
• Honda Accord [CL1] (1998-2004) – Accord Type R (H22A7)
